Rental K3 500x500
K3 Series P1.56/P1.95/P2.6/P2.97/P3.91 Outdoor and Indoor Rental LED Display
Product introduction |
K3 Series indoor/outdoor die-casting LED display is the third generation rental product Kensun launched, with more than 20 features upgraded and improved, while it only weighs only 7.5kg per cabinet.
Thin and lightweight
As an outdoor product with new aluminium structure design, K3 weighs only 7.5kg per cabient and measures only 83mm thick, it makes installation much easier and saves shipping cost.
High brightness and grayscale
As an outdoor product, K3 LED featuring hight brightness of 3500 nits and 13 bit gray scale, bringing an amazing and immersive visual experience, make every detail on display more eye-catching and readable.
Perfect alignment flatness
Cabinets are finished with module extrusion, result in precise and consistent cabinet
architecture, its accuracy is up to 0.05mm after CNC processing, a finely processed cabinet brings a better cabient alignment and visual experience.
Applicable in different enviroments
K3 is a weatherproof product with high brightness, it can works properly for most outdoor enviroments, at the same time, it can also be used for indoor events thanks to its light aluminum cabinet and wide brightness range.
Product Parameters
Item | Parameters |
---|---|
Pixel pitch | 1.56mm |
LED Type | SMD1010 1R1G1B |
LED Module Size | 250 x 250mm |
LED Module Resolution | 160x160 dots |
LED Cabinet Size | 500x500x83mm |
Cabinet Resolution | 320x320 dots |
Screen Pixel | 409600 dots |
Signal Processing | 13 bit |
Grey Level | 4096 - 65536 |
Refresh Rate | > 3840Hz |
Scan Mode | 1/64 |
Brightness | > 500 nits |
Viewing Distance | > 1.56m |
Viewing Angle | 120 degree |
Input Voltage | 110 - 240V/50-60Hz |
Max Consumption | 120W/PCS |
Ave Consumption | 50-80W/PCS |
Working Temperature | -10 degree to 60 degree |
Storage Temperature | -40 degree to 60 degree |
IP Rate | IP43 |
Working Humidity | 35% - 75% |
Storage Humidity | 10% - 90% |
Lifespan | 100,000 hours |
Service Type | Front & Rear Service |
LED Lamp | Nationalstar |
IC | ICN2153 |
Control Card | Nova / Colorlight |
Operation Approach | Windows |
Dual Signal/Power | Support |
