P2.5 Indoor 160x80MM

P2.5 Indoor Totally Front Service LED Screen

Product introduction |

Ultra thin, ultra light weight with 480X480mm and 7kg weight , small cabinet to handle easily, portable and convenient to installation, assembly and disassembly.

Cabinet Material:Cast Iron & Single Side Design

Application:Die-cast aluminum material made with the features of high precise, high hardness and high strength.

P2 I1.jpg

P2.5 Small Module

LED display module panel dimension is 160x80mm, the modules use unique design with Black Nationalstar SMD 2121 LED lamp Encapsulation, High quality with stable performance.


P2 I2.jpg

Strong Visual Impact

Pure black module mask and SMD2121 LED to make the LED display with higher contrast rate. 14 bit color depth to make the LED display with nature color and visual impact, giving viewer immersive feeling. High flatness, seamless connection using fast lock design, no gaps.

P2 I1.jpg

High Refresh Rate

High refresh rate up to 3840hz to realize high contrast, high definition with uniformity color effect. The display is perfect with clear image and visual present.


P2 I2.jpg

Quality-centric Approach

We focus on one-stop service for customised design and manufacturing to satisfy your various needs.

Product Parameters

ItemParameters
Pixel pitch2.5mm
LED TypeSMD2020 1R1G1B
LED Module Size160 x 80mm
LED Module Resolution64 x 32 dots
LED Cabinet Size640 x 80 x 22mm
Cabinet Resolution256 x 32 dots
Screen Pixel160,000 dots
Signal Processing 12 - 16 bit
Grey Level4096 - 65536
Refresh Rate> 3840Hz
Scan Mode1/32
Brightness>1,000 nits
Viewing Distance> 2.5m
Viewing Angle160 degree
Input Voltage
110-240V/50-60Hz
Max Consumption750W/SQ.M
Ave Consumption225W/SQ.M
Working Temperature-20 degree to 45 degree
Storage Temperature-40 degree to 60 degree
IP RateIP45
Working Humidity10% - 60%
Storage Humidity10% - 90%
Lifespan100,000 hours
Service TypeFront & Rear Service
LED Lamp
Nationalstar
ICICN2153
Control CardNova / Colorlight
Operation ApproachWindows
