P25-50 LED Bar Display

P25-50 LED Outdoor Bar Display

Product introduction |

High brightness LED bar display, extremely light weight, easy to assemble. It is durable and versatile for full outdoor humidity environment. This screen can be used for both rental business and fixed installation on the building wall.

Cabinet Material:Cast Iron & Double Sided Design

Application: High-precision die casting aluminum material cabinet, extremely light weight, easy to assemble.

2_ledbar 500x500.jpg

Easy To Install

High-precision slim long aluminum material bar cabinet, extremely light weight, easy to assemble.

1000x16.7x26mm module, compatible with the installation clips;Cabinet size 1000mm L x 22mm W x 33mm H, one cabinet 0.5KG very thin and light, quick install.



Perfect Performance

Super high brightness over 6000 nits, MBI driving IC, refresh ≥3840H, ensures true 16bit gray level. Ensure no deformation of PCB Board, perfect flatness performance. Showing the real and full angle display.



Support Front and Rear Access

Bar LED Display is accessible from the front side of the body. All cables, power supply, control card, Hub card and other electronic components can be removed from the front side and back side. You can easily replace the new parts and save a great of your time.



Applicable in Different Environments

LED Bar can be made to high brightness over 6,500 - 7,000 nits. It can work properly for all the indoor environment and some of the semi-outdoor places. At the same time, it can also be used for some indoor events because it has a very good brightness and the light weight aluminium cabinet body.


Product Parameters

ItemParameters
Pixel pitch25-50mm
LED TypeSMD346 1R1G1B
LED Module Size1000x16.7x26mm
LED Module Resolution40 dots per bar
LED Cabinet Size1000x22x33mm with clips
Cabinet Resolution40 dots
Screen Pixel800 dots per sq.m
Signal Processing 12 - 16 bit
Grey Level4096 - 65536
Refresh Rate> 3840Hz
Scan ModeStatic Drive
Brightness> 6000 nits
Viewing Distance> 25m
Viewing Angle160 degree
Input Voltage
110-240V/50-60Hz
Max Consumption750W/SQ.M
Ave Consumption225W/SQ.M
Working Temperature-20 degree to 45 degree
Storage Temperature-40 degree to 60 degree
IP RateIP67
Working Humidity10% - 60%
Storage Humidity10% - 90%
Lifespan100,000 hours
Service TypeFront & Rear Service
LED Lamp
Nationalstar
ICICN2153
Control CardNova / Colorlight
Operation ApproachWindows


Video Playback
